Technical Data
Dimensions : 800x1192x560 mm
Net weight : 178 kg
Hearth opening size : 635x245 mm
Hearth size : 590x320x350 mm
Smoke outlet diameter : 160 mm
Hearth : Ghisa-Ironker
Heatable : 441 m3
Power given back to water : 11,1 kW
Power given back to the room : 4,3 kW
Nominal thermal power : 15,4 kW
Global thermal power : 18,6 kW
Fluid contents of the exchanger : 20 l
Working pressure : 3 bar
Optimal working temperat. : 70°-75°
Ø Boiler connection : 1" F Gas
Adjustable primary air : Yes
Adjustable secondary air : Yes
Pre-adjusted tertiary air : Yes
Efficiency : 82,7 %
Hourly consumption : 4,3 kg/h
